ST26V TIG TORCH AX50 4M

ST26V TIG TORCH AX50 4M

  • TIG torch ST26V with 4m cable.
  • AX50 connector, 5-pin control cable, G 3/8 gas connector.
  • Hand wheel for gas opening.
  • Air cooling.
  • Max current 180A DC / 125A AC @35%.
  • TIG torch ST26V with 4m cable.
  • AX50 connector, 5-pin control cable, G 3/8 gas connector.
  • Hand wheel for gas opening.
  • Air cooling.
  • Max current 180A DC / 125A AC @35%.
TIG welding torch ST26V with 4-metre cable with 5-pin control connector. Gas adjustment takes place via the hand wheel on the handle (no button, contact trigger). The torch can work with maximum current 180A in DC and 125A in AC (@35%). Gas connector type G 3/8. With 2.4 mm DC electrode and relevant consumables.

CODE

742058

COOLING DOWN

AIR

CABLE LENGHT

4 m

CABLE SECTION

25 mm²

MAX. CURRENT

180A DC / 125A AC @35% A

CONNECTION

AX50

REMOTE CONTROL

no

STANDARD

EN 60974-7

DIMENSIONS

370x315x80 mm

WEIGHT

2,460 kg

Catalog Image

Download IMG

TIG welding torch ST26V with 4-metre cable with 5-pin control connector. Gas adjustment takes place via the hand wheel on the handle (no button, contact trigger). The torch can work with maximum current 180A in DC and 125A in AC (@35%). Gas connector type G 3/8. With 2.4 mm DC electrode and relevant consumables.

CODE

742058

COOLING

AIR

CABLE LENGTH

4 m

T04050

25 mm²

MAX CURRENT

180A DC / 125A AC @35% A

T04055

AX50

T04053

no

STANDARD

EN 60974-7

DIMENSIONS

370x315x80 mm

WEIGHT

2,460 kg

Catalog Image

Download IMG

TIG CONSUMABLES BOXES

CONSUMABLES BOX FOR TIG TORCH ST17-26

804138
TIG CONSUMABLES

ELECTRODE DIFFUSERS Ø 1 MM 3 PCS

802249

ELECTRODE DIFFUSERS Ø 1,6 MM 3 PCS

802250

ELECTRODE DIFFUSERS Ø 2,4 MM 3 PCS

802251

ELECTRODE DIFFUSERS Ø 4 MM 3 PCS

802253

KIT 3 ELECTRODE HOLDER CLAMPS D.3,2 MM

802242

KIT 3 ELECTRODE HOLDER CLAMPS D.4 MM

802243

KIT 10 CERAMIC NOZZLES NR.4

802244

KIT 10 CERAMIC NOZZLES NR.6

802245

KIT 10 CERAMIC NOZZLES NR.7

802246

KIT 10 CERAMIC NOZZLES NR.8

802247

SHORT CAP ST17-26

722192

LONG CAP

722193
SPECIAL TIG CONSUMABLES

CRYSTAL CHAMPAGNE BOX D. 1,6 MM

804202

CRYSTAL CLEAR CUP - LONG - BOX D. 1,6 MM

804206

CRYSTAL CHAMPAGNE BOX D. 2,4 MM

804203

CRYSTAL CLEAR CUP - LONG - BOX D. 2,4 MM

804207

CRYSTAL CLEAR CUP - BOX D. 2,4 MM

804205

CRYSTAL CLEAR CUP - BOX D. 1,6 MM

804204
BLISTER ACCESSORIES

TIG TORCH MAGNETIC HOLDER

804127
